R410A 3phase 160kw Water Ground Source Heat Pump Renewable Energy Utilization Technology

Brand Name:	DUHM
Model Number:	WBC-160.0H-B-S(KE-BB)
MOQ:	2
Price:	Negotiable
Packaging Details:	CARTON
Payment Terms:	T/T, L/C AT SIGHT

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

After-sales Service Provided:

Free Spare Parts

Warranty:

1 Year

Operating Language:

English

Application:

Hotel, Garage, Commercial, Household

Power Source:

Electric

App-Controlled:

Logo/pattern:

Silk Screen Printing

Type:

Water Source Heat Pump, Geothermal Heatpump

Storage / Tankless:

Instant / Tankless

Housing Material:

Metal

Hotel,House Houlds

Function:

Water Source Heatpump

Refrigerant:

R410A

Compressor:

Copland

Name:

Water & Ground Source Heat Pump

Power Supply:

380V/50Hz/3ph

Heat Source:

Water+ground Source

Color:

White

Material:

Galvanized Steel With Powder Coated

OEM Service:

Supported

Supply Ability:

800 SETS/DAY

Highlight:

R410A ground source heat pump

ground source heat pump 160kw

3phase water source heat pump manufacturers

Product Description

Renewable Energy Utilization Technology R410A 3phase 160kw Water Ground Source Heat Pump

Model						WBC-19.5H-B-S(KE-BB)	WBC-22.0H-B-S(KE-BB)	WBC-31.0H-B-S(KE-BB)	WBC-39.5H-B-S(KE-BB)
Horse					(P)	5	6	8	10
Heating Condition : Water: 15-10°C Out 40-45°C	Heating Capacity			KW	19.8	22.8	31.7	39.6
		Heating Power Input			KW	4.4	5.1	7.0	8.8
		Currency			A	7.87	9.05	12.59	15.74
		COP			W/W	4.5	4.5	4.5	4.5
Cooling Condition: W30-35°C Out W12-7°C	Cooling Capacity			KW	15.3	17.5	24.4	30.5
		Heating Power Input			KW	4.0	4.6	6.4	8.0
		Currency			A	7.2	8.3	11.5	14.3
		EER			W/W	3.8	3.8	3.8	3.8
Max. Power Input					KW	6.6	7.6	10.6	13.2
Max Currency					A	11.8	13.6	18.9	23.6
Power Supply					V/PH/HZ	380V/3PH/50HZ
Circulating Water Flow					m³/h	3.4	3.9	5.4	6.8
Operating Ambient Temperature (℃)					°C	10~45
Water Pressure Drop (max.)					Kpa	20	20	30	40
Rated Outlet Water Temperature /Cooling					°C	45/7
Max Outlet Water Temperature /Min. Outlet Water Temperature					°C	60/5
Pipework Size					inch	4*G1"	4*G1"	4*G1.5"	4*G1.5"
QTY of Water Pump					Set	0	0	0	0
QTY of Comperssor					Set	1	1	1	1
QTY of Fans					Set	0	0	0	0
Refrigerant / Qty					kg	R410a/3kg	R410a/4kg	R410a/5kg	R410a/6kg
Noise					dB(A)	46	46	56	56
Unit Dimension			L / W / H	mm	720570920	720570920	9056701000	9056701000
Shipping Dimension			L / W / H	mm	7605951035	7605951035	9406951115	9406951115
Net Weight /Gross Weight					kg	130/140	130/140	205/215	205/215

Model						WBC-45.0H-B-S(KE-BB)	WBC-100.0H-B-S(KE-BB)	WBC-160.0H-B-S(KE-BB)
Horse					(P)	12	25	40
Heating Condition : Water: 15-10°C Out 40-45°C	Heating Capacity			KW	45.8	100.0	160.8
		Heating Power Input			KW	10.2	22.2	35.7
		Currency			A	18.21	39.75	63.92
		COP			W/W	4.5	4.5	4.5
Cooling Condition: W30-35°C Out W12-7°C	Cooling Capacity			KW	36.6	73.2	117.1
		Heating Power Input			KW	9.6	19.3	30.8
		Currency			A	17.2	34.5	55.1
		EER			W/W	3.8	3.8	3.8
Max. Power Input					KW	15.3	33.3	53.6
Max Currency					A	27.3	59.6	95.9
Power Supply					V/PH/HZ	380V/3PH/50HZ
Circulating Water Flow					m³/h	7.9	17.2	27.5
Operating Ambient Temperature (℃)					°C	10~45
Water Pressure Drop (max.)					Kpa	40	50	60
Rated Outlet Water Temperature /Cooling					°C	45/7
Max Outlet Water Temperature /Min. Outlet Water Temperature					°C	60/5
Pipework Size					inch	4*G1.5"	4*G2.5"	4*DN80
QTY of Water Pump					Set	0	0	0
QTY of Comperssor					Set	1	1	4
QTY of Fans					Set	0	0	0
Refrigerant / Qty					kg	R410a/6.5kg	R410a/8kg	R410a/5.5kg*4
Noise					dB(A)	56	56	62
Unit Dimension			L / W / H	mm	9056701000	130011001270	18609001490
Shipping Dimension			L / W / H	mm	9406951115	133511201385	18959201605
Net Weight /Gross Weight					kg	215/225	385/420	825/840
