Ultra Low Temperature Inverter R32 Monoblock Special Edition Heat Pump for Underfloor Heating

Brand Name:	Wotech
Model Number:	HM10VM
MOQ:	2
Price:	Negotiable
Packaging Details:	Polywood Pallet
Payment Terms:	T/T,L/C AT SIGHT

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

After-sales Service Provided:

Free Spare Parts

Warranty:

1 Year

Application:

Hotel, Garage, Commercial, Household

Power Source:

Electric

Logo/pattern:

Silk Screen Printing

Type:

Air Source Heat Pump, Monoblock

Heating Source:

Air To Water Heat Pump

Function:

Heating+Cooling

Refrigerant:

Housing Material:

Galvanized Steel With Powder Coated

ErP Rating (35℃/55℃):

A++/A+

Supply Ability:

800 Sets/Day

Highlight:

R32 inverter monoblock heat pump

ultra low temperature heat pump

underfloor heating heat pump

Product Description

Ultra Low Temperature Inverter R32 Monoblock Special Edition Heat Pump for Underfloor Heating

Ultra Low Temperature Full DC Inverter Unit

Ultra Low Temperature Inverter R32 Monoblock Special Edition Heat Pump for Underfloor Heating 0

Excellent Performance Unleashes Power

Ultra Low Temperature Inverter R32 Monoblock Special Edition Heat Pump for Underfloor Heating 1 Residential Heating & Cooling Solutions

Whole house constant temperature heating+central air conditioning+domestic hot water to create a comfortable and healthy living environment that feels like spring all year round

Ultra Low Temperature Inverter R32 Monoblock Special Edition Heat Pump for Underfloor Heating 2

Specifications

Model			HM10VM	HM12VM	HM16VM	HM20VM	HM16VT	HM20VT	HM26VT	HM35VT
Power supply		V/Ph/Hz	220-240/1/50	220-240/1/50	220-240/1/50	220-240/1/50	380-415/3/50	380-415/3/50	380-415/3/50	380-415/3/50
Performance Condition:Outdoor air 7℃/6℃,Inlet/Outlet water 30℃/35℃
Heating	Capacity	kW	3.8～10.5	5.0～12.2	5.6～16.8	7.2～20.2	5.6～16.8	7.2～20.2	12.8～26.6	16.5～35.3
	Rated input	kW	0.8～3.3	0.9～3.6	1.1～5.1	1.6～5.8	1.1～5.1	1.6～5.8	2.9～7.6	3.8～10.1
	SCOP		4.31	4.33	4.28	4.23	4.27	4.23	4.22	4.25
Performance Condition:Outdoor air7℃/6℃,Inlet/Outlet water 50℃/55℃
Heating	Capacity	kW	3.9～10.6	5.2～12.4	5.8～16.9	7.4～20.5	5.8～16.9	7.4～20.5	13.1～26.8	16.8～35.6
	Rated input	kW	1.0～3.8	1.3～4.4	1.5～6.1	1.9～7.3	1.5～6.1	1.9～7.3	3.3～9.5	4.2～12.7
	SCOP		3.38	3.32	3.33	3.38	3.33	3.38	3.51	3.53
Performance Condition:Outdoor air 35℃/24℃,Inlet/Outlet water 12℃/7℃
Cooling	Capacity	kW	3.1-7.8	4.1～10.1	5.0～12.5	6.3～15.8	5.0～12.5	6.3～15.8	7.0～17.5	9.8~24.5
	Rated input	kW	1.0～2.9	1.3～3.7	1.6～45	2.0～5.7	1.6～45	2.0～5.7	2.2～6.3	3.1～8.6
	EER		2.72	2.73	2.75	2.78	2.75	2.78	2.81	2.86
Energy class (SCOP)	Outlet water temp at 35℃		A++
Energy class (SCOP)	Outlet water temp.at 55℃		A++
Refrigerant	Type		R32
Noise level	Heating	dB(A)	52	52	54	55	57	55	56	58
Noise level	Cooling	dB(A)	50	50	52	53	52	53	54	56
Water flow volume		m³/h	1.72	2.06	2.75	3.44	2.75	3.44	4.47	6.02
Water piping connections		mm	DN25 Male	DN25 Male	DN25 Male	DN25 Male	DN25 Male	DN25 Male	DN32 Male	DN40 Male
Operating Temperature Range	Cooling	℃	15～45
	Heating	℃	-30～45
	DHW	℃	-30～45
Net dimensions(WDH)		mm	960380690	960380690	10353851340	10353851340	10353851340	10353851340	10353851340	11204301550
Packed dimensions(WDH)		mm	1040450750	1040450750	10554321480	10554321480	10554321480	10554321480	10554321480	11604731695
Net/Gross weight		kg	57	60	98	110	102	110	112	145
*Please refer to the nameplate for product upgrades or changes in specifications without prior notice
