380V Inverter R32 Monoblock Special Edition Heat Pump for Heating & Cooling -35℃ operature

Brand Name:	Wotech
Model Number:	HM20VT
MOQ:	2
Price:	Negotiable
Packaging Details:	Polywood Pallet
Payment Terms:	T/T,L/C AT SIGHT

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

After-sales Service Provided:

Free Spare Parts

Warranty:

1 Year

Application:

Hotel, Garage, Commercial, Household

Power Source:

Electric

Logo/pattern:

Silk Screen Printing

Type:

Air Source Heat Pump, Monoblock

Heating Source:

Air To Water Heat Pump

Function:

Heating+Cooling

Refrigerant:

Housing Material:

Galvanized Steel With Powder Coated

Power Supply:

380V-50Hz-3Phase

Supply Ability:

800 Sets/Day

Highlight:

380V R32 inverter heat pump

monoblock heat pump for heating cooling

R32 heat pump with -35℃ operation

Product Description

380V Inverter R32 Monoblock Special Edition Heat Pump for Heating & Cooling -35℃ operature

Ultra Low Temperature Full DC Inverter Unit

380V Inverter R32 Monoblock Special Edition Heat Pump for Heating & Cooling -35℃ operature 0

Excellent Performance Unleashes Power

380V Inverter R32 Monoblock Special Edition Heat Pump for Heating & Cooling -35℃ operature 1 Residential Heating & Cooling Solutions

Whole house constant temperature heating+central air conditioning+domestic hot water to create a comfortable and healthy living environment that feels like spring all year round

380V Inverter R32 Monoblock Special Edition Heat Pump for Heating & Cooling -35℃ operature 2

Specifications

Model			HM10VM	HM12VM	HM16VM	HM20VM	HM16VT	HM20VT	HM26VT	HM35VT
Power supply		V/Ph/Hz	220-240/1/50	220-240/1/50	220-240/1/50	220-240/1/50	380-415/3/50	380-415/3/50	380-415/3/50	380-415/3/50
Performance Condition:Outdoor air 7℃/6℃,Inlet/Outlet water 30℃/35℃
Heating	Capacity	kW	3.8～10.5	5.0～12.2	5.6～16.8	7.2～20.2	5.6～16.8	7.2～20.2	12.8～26.6	16.5～35.3
	Rated input	kW	0.8～3.3	0.9～3.6	1.1～5.1	1.6～5.8	1.1～5.1	1.6～5.8	2.9～7.6	3.8～10.1
	SCOP		4.31	4.33	4.28	4.23	4.27	4.23	4.22	4.25
Performance Condition:Outdoor air7℃/6℃,Inlet/Outlet water 50℃/55℃
Heating	Capacity	kW	3.9～10.6	5.2～12.4	5.8～16.9	7.4～20.5	5.8～16.9	7.4～20.5	13.1～26.8	16.8～35.6
	Rated input	kW	1.0～3.8	1.3～4.4	1.5～6.1	1.9～7.3	1.5～6.1	1.9～7.3	3.3～9.5	4.2～12.7
	SCOP		3.38	3.32	3.33	3.38	3.33	3.38	3.51	3.53
Performance Condition:Outdoor air 35℃/24℃,Inlet/Outlet water 12℃/7℃
Cooling	Capacity	kW	3.1-7.8	4.1～10.1	5.0～12.5	6.3～15.8	5.0～12.5	6.3～15.8	7.0～17.5	9.8~24.5
	Rated input	kW	1.0～2.9	1.3～3.7	1.6～45	2.0～5.7	1.6～45	2.0～5.7	2.2～6.3	3.1～8.6
	EER		2.72	2.73	2.75	2.78	2.75	2.78	2.81	2.86
Energy class (SCOP)	Outlet water temp at 35℃		A++
Energy class (SCOP)	Outlet water temp.at 55℃		A++
Refrigerant	Type		R32
Noise level	Heating	dB(A)	52	52	54	55	57	55	56	58
Noise level	Cooling	dB(A)	50	50	52	53	52	53	54	56
Water flow volume		m³/h	1.72	2.06	2.75	3.44	2.75	3.44	4.47	6.02
Water piping connections		mm	DN25 Male	DN25 Male	DN25 Male	DN25 Male	DN25 Male	DN25 Male	DN32 Male	DN40 Male
Operating Temperature Range	Cooling	℃	15～45
	Heating	℃	-30～45
	DHW	℃	-30～45
Net dimensions(WDH)		mm	960380690	960380690	10353851340	10353851340	10353851340	10353851340	10353851340	11204301550
Packed dimensions(WDH)		mm	1040450750	1040450750	10554321480	10554321480	10554321480	10554321480	10554321480	11604731695
Net/Gross weight		kg	57	60	98	110	102	110	112	145
*Please refer to the nameplate for product upgrades or changes in specifications without prior notice
